Gigabyte Intel Chipset H410M H Micro ATX Motherboard

https://www.dolphin.com.bd/web/image/product.template/7123/image_1920?unique=a58e0fa

Gigabyte H410M H
CPU Sockets – LGA1200
Chipset – Intel H410 Express
Generation – 10th

8,500.00 ৳ 8500.0 BDT 8,500.00 ৳

8,500.00 ৳

Not Available For Sale

    This combination does not exist.


    Share :
    Supported CPU

    Support For 10th Generation Intel Core I9 Processors/ Intel Core I7 Processors/ Intel Core I5 Processors/ Intel Core I3 Processors/ Intel Pentium Processors/ Intel Celeron Processors In The LGA1200 Package
    L3 Cache Varies With CPU

    ChipsetIntel H410 Express Chipset
    Supported Memory1 X M.2 Connector (Socket 3, M Key, Type 2242/2260/2280 SATA And PCIe X2 SSD Support) 4 X SATA 6Gb/S Connectors
    BIOS1 X 128 Mbit Flash Use Of Licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
    RAM TypeDDR4
    FromFactorMicro ATX Form Factor; 22.6cm X 17.4cm
    Internal I/O Ports1 X 24-Pin ATX Main Power Connector 1 X 8-Pin ATX 12V Power Connector 1 X CPU Fan Header 1 X System Fan Header 1 X RGB LED Strip Header 4 X SATA 6Gb/S Connectors 1 X M.2 Socket 3 Connector 1 X Front Panel Header 1 X Front Panel Audio Header 1 X USB 3.2 Gen 1 Header 1 X USB 2.0/1.1 Header 1 X Trusted Platform Module Header (For The GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 Module Only) 1 X Serial Port Header 1 X Clear CMOS Jumper
    Maximum Memory64 GB
    Max Shared Memory512MB
    AudioRealtek ALC887 Codec High Definition Audio 2/4/5.1/7.1-Channel
    Expansion Slots

    2 X DDR4 DIMM

    HDMI1 X HDMI
    LANRealtek GbE LAN Chip (1000 Mbit/100 Mbit)
    Graphics

    Integrated Graphics Processor-Intel HD Graphics Support:
    1 X D-Sub Port, Supporting A Maximum Resolution Of 1920×1200@60 Hz
    1 X HDMI Ports, Supporting A Maximum Resolution Of 4096×2160@30 Hz

    USB4 X USB 3.2 Gen 1 Ports (2 Ports On The Back Panel, 2 Ports Available Through The Internal USB Header) 6 X USB 2.0/1.1 Ports (4 Ports On The Back Panel, 2 Ports Available Through The Internal USB Header)
    BrandIntel



    Find Your Desired Gigabyte Intel Chipset H410M H Micro ATX Motherboard Price In Bangladesh From Dolphin. This Gigabyte Intel Chipset H410M H Micro ATX Motherboard supports DDR4 Ram. Buy H410M H Micro Motherboard Price at low From Dolphin. We Provide the best quality at the lowest price.

    Gigabyte Intel Chipset H410M H Micro ATX Motherboard Price in Bangladesh

    Basic Information

    Supported CPUSupport for 10th Generation Intel Core i9 processors/ Intel Core i7 processors/ Intel Core i5 processors/ Intel Core i3 processors/ Intel Pentium processors/ Intel Celeron processors in the LGA1200 package
    L3 cache varies with CPU
    ChipsetIntel H410 Express Chipset
    BIOS1 x 128 Mbit flash
    Use of licensed AMI UEFI BIOS
    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
    Form FactorMicro ATX Form Factor; 22.6cm x 17.4cm

    Expansion Slots

    PCI1 x PCI Express x16 slot, running at x16
    2 x PCI Express x1 slots
    M.2 Socket1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x2 SSD support)

    Memory

    TypeDual-channel architecture
    Slots2 x DDR4 DIMM
    Supported MemoryIntel® Core™ i9/i7 processors:
    Support for DDR4 2933/ 2666/ 2400/ 2133 MHz memory modules
    Intel Core i5/ i3/ Pentium /Celeron processors:
    Support for DDR4 2666/ 2400/ 2133 MHz memory modules
    Maximum Memory64 GB

    Graphics

    GraphicsIntegrated Graphics Processor-Intel HD Graphics support:
    1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz
    1 x HDMI ports, supporting a maximum resolution of 4096×2160@30 Hz
    Max Shared Memory512MB

    Connector & Ports

    HDMI1 x HDMI ports, supporting a maximum resolution of 4096×2160@30 Hz
    USB (s)4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
    6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
    LAN Port (s)Realtek GbE LAN chip (1000 Mbit/100 Mbit)
    Supported Storage1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x2 SSD support)
    4 x SATA 6Gb/s connectors
    AudioRealtek ALC887 codec
    High Definition Audio
    2/4/5.1/7.1-channel
    Internal I/O Ports1 x 24-pin ATX main power connector
    1 x 8-pin ATX 12V power connector
    1 x CPU fan header
    1 x system fan header
    1 x RGB LED strip header
    4 x SATA 6Gb/s connectors
    1 x M.2 Socket 3 connector
    1 x front panel header
    1 x front panel audio header
    1 x USB 3.2 Gen 1 header
    1 x USB 2.0/1.1 header
    1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
    1 x serial port header
    1 x Clear CMOS jumper
    Special FeaturesSupport for APP Center
    @BIOS
    Ambient LED
    EasyTune
    Fast Boot
    Game Boost
    ON/OFF Charge
    Smart Backup
    System Information Viewer
    Support for Q-Flash
    Support for Xpress Install

    Warranty Information

    Manufacturing Warranty03 years warranty

    Gigabyte Intel Chipset H410M H Micro ATX Motherboard Price in BD

    Gigabyte Intel Chipset H410M Ultra Durable Motherboard with GIGABYTE 8118 Gaming LAN, Anti-Sulfur Resistor, Smart Fan 5 Supports 10th Gen Intel®Core™ Processors Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs 8-Channel HD Audio with High-Quality Audio Capacitors GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP GIGABYTE APP Center, Simple and Easy Use
    Anti-Sulfur Resistors Design.

    D-Sub
    HDMI
    USB 3.1 Gen1 Type-A
    Realtek 8118 Gaming LAN
    Audio Noise Guard
    Audio Capacitors
    High-Quality Onboard Audio Design
    Dual-Channel DDR4, 2 DIMMs
    Supports 10th Gen Intel® Core™ Process
    SATA 6Gb/s
    USB3.2 Gen1 Header
    M.2 Connector

    Gigabyte Intel Chipset H410M Gaming LAN
    High-Speed Gigabit LAN with Automatic Bandwidth Allocation. Gigabyte Intel Chipset H410M is a high-performance and friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users with the most comprehensive features and the fastest and smoothest Internet experience.

    Smart Fan 5
    With Smart Fan, 5 users can ensure that their gaming PC can maintain its performance while staying cool. Smart Fan 5 allows users to interchange their fan headers to reflect different thermal sensors at different locations on the motherboard. Not only that, with Smart Fan, 5 more hybrid fan headers that support both PWM and Voltage mode fans have been introduced to make the motherboard more liquid cooling friendly.
