MSI B450M PRO-VDH MAX AMD AM4 Gaming Motherboard

https://www.dolphin.com.bd/web/image/product.template/6806/image_1920?unique=a58e0fa


Brand: MSI
Model: MSI B450M PRO-VDH MAX
Supports 1st, 2nd and 3rd Gen AMD Ryzen
Memory up to 3466+(OC) MHz
PCI-E Gen3 x4 maximizes performance
PCI-E Steel Armor

9,010.00 ৳ 9010.0 BDT 9,010.00 ৳

9,010.00 ৳

Not Available For Sale

    This combination does not exist.


    Share :
    More Information
    Supported CPU

    Supports 1st, 2nd And 3rd Gen AMD Ryzen/ Ryzen With Radeon Vega Graphics And 2nd Gen AMD Ryzen With Radeon Graphics/ Athlon With Radeon Vega Graphics Desktop Processors For Socket AM4

    ChipsetAMD B450 Chipset
    Supported MemorySupports 1866/ 2133/ 2400/ 2667Mhz (By JEDEC) For AMD Ryzen Gen3 (R5/R7/R9) Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3733/ 3866 MHz (By A-XMP OC MODE) For AMD Other Processors Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (By A-XMP OC MODE) Supports Dual Channel Mode Supports ECC UDIMM Memory (Non-ECC Mode) Support Non-ECC UDIMM Memory
    RAM TypeDDR4
    FromFactor9.6 In. X 9.6 In. (24.4 Cm X 24.4 Cm) M-ATX Form Factor
    Internal I/O Ports1 X 24-Pin ATX Main Power Connector 1 X 8-Pin ATX 12V Power Connector 4 X SATA 6Gb/S Connectors 2 X USB 2.0 Connectors (Supports Additional 4 USB 2.0 Ports) 1 X USB 3.1 Gen1 Connector (Supports Additional 2 USB 3.1 Gen1 Ports) 1 X 4-Pin CPU Fan Connector 2 X 4-Pin System Fan Connectors 1 X Front Panel Audio Connector 2 X Front Panel Connectors 1 X Chassis Intrusion Connector 1 X Serial Port Connector 1 X Parallel Port Connector 1 X RGB LED Strip Connector 1 X Clear CMOS Jumper
    Maximum Memory64GB
    Max Shared MemoryMaximum Shared Memory Of 2048 MB
    AudioRealtek ALC892 Codec 7.1-Channel High Definition Audio
    Operating SystemWindows 7, 10
    HDMIYes
    LAN1 X Realtek 8111H Gigabit LAN Controller
    Graphics

    Onboard Graphics

    USBAMD B450 Chipset 2 X USB 3.2 Gen1 (SuperSpeed USB) Ports Through The Internal USB 3.2 Gen1 Connector 8 X USB 2.0 (High-Speed USB) Ports (4 Ports On The Back Panel, 4 Ports Available Through The Internal USB Connectors) AMD Processor 4 X USB 3.2 Gen1 (Supe
    Wi-FiNo
    BrandMSI


    MSI B450M PRO-VDH MAX AMD AM4 Gaming Motherboard Best Price in Bangladesh

    Find MSI B450M PRO-VDH MAX AMD AM4 Gaming Motherboard Best Price in Bangladesh. Find also other MotherBoard on reasonable from our website. You will get home delivery in Dhaka city or pickup from our showroom.

    Basic Information

    Supported CPUSupports 1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics/ Athlon with Radeon Vega Graphics Desktop Processors for Socket AM4
    ChipsetAMD B450 Chipset
    Form Factor 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
    m-ATX Form Factor

    Expansion Slots

    PCI1 x PCIe 3.0 x16 slot
    1st, 2nd and 3rd Gen AMD Ryzen support x16 mode
    Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics support x8 mode
    Athlon with Radeon Vega Graphics support x4 mode
    2 x PCIe 2.0 x1 slots
    M.2 Socket1 x M.2 slot (Key M)
    Supports PCIe 3.0 x4 (1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics) or PCIe 3.0 x2 (Athlon with Radeon Vega Graphics) and SATA 6Gb/s
    Supports 2242/ 2260 /2280 storage devices

    Memory

    Type

    Dual Channel Architecture

    Slots4 x DDR4 memory slots
    Supported Memory Supports 1866/ 2133/ 2400/ 2667Mhz (by JEDEC)
    For AMD Ryzen Gen3 (R5/R7/R9)
    Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3733/ 3866 MHz (by A-XMP OC MODE)
    For AMD Other Processors
    Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (by A-XMP OC MODE)
    Supports Dual Channel mode
    Supports ECC UDIMM memory (non-ECC mode)
    Support non-ECC UDIMM memory
    Maximum Memory64GB

    Graphics

    Graphics1 x VGA port, supports a maximum resolution of 2048x1280@60Hz, 1920x1200@60Hz
    1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
    1 x HDMI™ 1.4 port, supports a maximum resolution of 4096x2160 @30Hz, 2560x1600 @60Hz
    Max Shared MemoryThe maximum shared memory of 2048 MB

    Connector & Ports

    HDMI1 x HDMI 1.4 port (resolution of 4096x2160 @30Hz, 2560x1600 @60Hz)
    DVI-D (s)Yes1 x DVI-D port (resolution of 1920x1200@60Hz)
    USB (s)AMD B450 Chipset
    2 x USB 3.2 Gen1 (SuperSpeed USB) ports through the internal USB 3.2 Gen1 connector
    8 x USB 2.0 (High-speed USB) ports (4 ports on the back panel, 4 ports available through the internal USB connectors)
    AMD processor
    4 x USB 3.2 Gen1 (SuperSpeed USB) Type-A ports on the back panel
    LAN Port (s)1 x Realtek 8111H Gigabit LAN controller
    Supported StorageAMD B450 Chipset
    4 x SATA 6Gb/s ports
    Supports RAID 0, RAID1 and RAID 10
    1 x M.2 slot (Key M)
    Supports PCIe 3.0 x4 (1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics) or PCIe 3.0 x2 (Athlon with Radeon Vega Graphics) and SATA 6Gb/s
    Supports 2242/ 2260 /2280 storage devices
    AudioRealtek ALC892 Codec
    7.1-Channel High-Definition Audio
    Internal I/O Ports1 x 24-pin ATX main power connector
    1 x 8-pin ATX 12V power connector
    4 x SATA 6Gb/s connectors
    2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
    1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
    1 x 4-pin CPU fan connector
    2 x 4-pin system fan connectors
    1 x Front panel audio connector
    2 x Front panel connectors
    1 x Chassis Intrusion connector
    1 x Serial port connector
    1 x Parallel port connector
    1 x RGB LED strip connector
    1 x Clear CMOS jumper
    TPM (Trusted Platform Module )

    1 x TPM module connector

    Warranty Information

    Manufacturing Warranty03 Years Warranty

    Others

    Special FeaturesSupports 1st, 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics / Athlon with Radeon Vega Graphics Desktop Processors for Socket AM4, Supports DDR4 Memory, up to 3466+(OC) MHz, Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs., DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability, Audio Boost: Reward your ears with studio grade sound quality, EZ Debug LED: Easiest way to troubleshoot, Core Boost: With premium layout and fully digital power design to support more cores and provide better performance, PCI-E Steel Armor: Protecting VGA cards against bending and EMI

    MSI B450M PRO-VDH MAX AMD AM4 Gaming Motherboard

    MSI B450M motherboards feature tons of convenient and smart design, such as convenient pin-header keep out zone, friendly SATA & USB location and so on, so DIY users can pick and choose any gaming rig they want. MSI B450M motherboards let you manage speeds and temperatures for all your system and CPU fans, giving you full control to set up a cool & silent system. The fan headers are conveniently placed with the most popular CPU coolers in mind. MSI B450M motherboard is certified by a strict mechanic that features a convenient pin-header keep out zone, friendly SATA & USB location for compatibility with the widest range of components and devices, so DIY users can pick and choose the components they want. More than that, we offer a dedicated Qualified Vendor List (QVL) for the most critical part - memory. Combining with MSI DDR4 Boost technology, we provide the maximum compatibility, so you confirm and choose any gaming rig as you want. With years of experience in creating performance enhancing tools that are easy to use, only the highest quality applications are at your disposal. Use these tools to get the most out of your motherboard and achieve victory when gaming. Moreover, we made sure our BIOS contains all the latest options and is easy to use for everyone. The extensive features let you fine-tune your system to deliver reliable maximum performance. This unique and exclusive software allows you to boost the performance of any storage or USB device connected to your system. Simply use X-BOOST’s Easy or Advanced mode to tune your system speed increased, higher system responsiveness and faster loading of data. MSI B450M PRO-VDH MAX AMD AM4 Gaming motherboards featured all the latest solutions for enthusiast gamers and prosumers. CPU and memory enhancement and fast storage and USB transfer speed are ready to be on the battlefield. High quality materials and smart fan optimizations contribute to cooling all essential components, which is key to making sure your system runs stable and delivers the best performance at all times. MSI B450M PRO-VDH motherboard Core Boost technology combines MSI B450M premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU, also creating the perfect conditions for your CPU overclocking. Optimized layout design and a fully isolated memory circuitry ensures perfect stability and performance. you never have to worry about your system crashing during games with MSI DDR4 BOOST. MSI B450M PRO-VDH motherboards provide the most fascinating in-studio advantages, designed to satisfy any professional workflow. Elevate your listening pleasure and network connection with MSI Audio & LAN. Enjoy extreme sound quality and uninterrupted online experience.MSI B450M PRO-VDH MAX AMD AM4 Gaming Motherboard has a 03 year warranty.
