Gigabyte B560M DS3H Intel 10th and 11th Gen Micro ATX Motherboard

https://www.dolphin.com.bd/web/image/product.template/7125/image_1920?unique=a84a603


Brand: Gigabyte
Model: B560M DS3H
Supports 11th and 10th Gen Intel Core Processors
Dual Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2
Dual-Channel DDR4, 4 DIMMs
GIGABYTE Exclusive 8118 Gaming LAN

10,630.00 ৳ 10630.0 BDT 10,630.00 ৳

10,630.00 ৳

Not Available For Sale

    This combination does not exist.

    Contact Us
    Share :
    Terms and Conditions
    Supported CPU

    11th Generation Intel Core I9 Processors / Intel Core I7 Processors / Intel Core I5 Processors
    10th Generation Intel Core I9 Processors / Intel Core I7 Processors / Intel Core I5 Processors / Intel Core I3 Processors/ Intel Pentium Processors / Intel Celeron Processors

    ChipsetIntel B560 Express Chipset
    Supported Memory11th Generation Intel Core I9/I7/I5 Processors: Support For DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133 MHz 10th Generation Intel Core I9/I7 Processors: Support For DDR4 2933/2666/2400/2133 MHz Memory Modules 10th Generation Intel Core I5/I3/Pentium/Celeron Processors: Support For DDR4 2666/2400/2133 MHz Memory Modules 4 X DDR4 DIMM Sockets Supporting Up To 128 GB (32 GB Single DIMM Capacity) Of System Memory Dual Channel Memory Architecture Support For ECC Un-Buffered DIMM 1Rx8/2Rx8 Memory Modules (Operate In Non-ECC Mode) Support For Non-ECC Un-Buffered DIMM 1Rx8/2Rx8/1Rx16 Memory Modules Support For Extreme Memory Profile (XMP) Memory Modules
    BIOS1 X 256 Mbit Flash Use Of Licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
    RAM TypeDDR4
    FromFactorMicro ATX Form Factor; 24.4cm X 24.4cm
    Internal I/O Ports1 X 24-Pin ATX Main Power Connector 1 X 8-Pin ATX 12V Power Connector 1 X CPU Fan Header 3 X System Fan Headers 1 X Addressable LED Strip Header 1 X RGB LED Strip Header 6 X SATA 6Gb/S Connectors 2 X M.2 Socket 3 Connectors 1 X Front Panel Header 1 X Front Panel Audio Header 1 X USB 3.2 Gen 1 Header 2 X USB 2.0/1.1 Headers 1 X Serial Port Header 1 X Parallel Port Header 1 X Clear CMOS Jumper 1 X Q-Flash Plus Button
    Maximum Memory128 GB (32 GB Single DIMM Capacity)
    AudioRealtek Audio CODEC High Definition Audio 2/4/5.1/7.1-Channel
    Expansion Slots
    PCI1 X PCI Express X16 Slot, Running At X16
    (The PCIEX16 Slot Conforms To PCI Express 4.0 Standard.) (Note)
    2 X PCI Express X1 Slots
    (The PCIEX1 Slot Conforms To PCI Express 3.0 Standard.)
    M.2 Socket1 X M.2 Connector (Socket 3, M Key, Type 2260/2280/22110 PCIe 4.0 X4/X2 SSD Support) (M2P_CPU) (Note)
    Chipset:
    1 X M.2 Connector (Socket 3, M Key, Type 2260/2280 SATA And PCIe 3.0 X4/ X2 SSD Support) (M2A_SB)
    HDMI1 X HDMI Port, Supporting A Maximum Resolution Of 4096x2160@30 Hz
    LANRealtek GbE LAN Chip (1000/100 Mbit)
    Graphics

    Integrated Graphics Processor-Intel HD Graphics Support:
    1 X D-Sub Port, Supporting A Maximum Resolution Of 1920x1200@60 Hz
    1 X DVI-D Port, Supporting A Maximum Resolution Of 1920x1200@60 Hz
    * The DVI-D Port Does Not Support D-Sub Connection By Adapter.
    1 X DisplayPort, Supporting A Maximum Resolution Of 4096x2304@60 Hz
    * Support For DisplayPort 1.2 Version And HDCP 2.3
    * When The D-Sub Port And DisplayPort Are Connected At The Same Time, Images Will Output From The DisplayPort Only.
    1 X HDMI Port, Supporting A Maximum Resolution Of 4096x2160@30 Hz
    * Support For HDMI 1.4 Version And HDCP 2.3.
    Support For Up To 3 Displays At The Same Time

    USBChipset: 1 X USB Type-C Port On The Back Panel, With USB 3.2 Gen 1 Support 5 X USB 3.2 Gen 1 Ports (3 Ports On The Back Panel, 2 Ports Available Through The Internal USB Header) 4 X USB 2.0/1.1 Ports Available Through The Internal USB Headers Chipset+USB
    Audio Jack3 X Audio Jacks
    DisplayPort1 X DisplayPort, Supporting A Maximum Resolution Of 4096x2304@60 Hz
    Supported Storage1 X M.2 Connector (Socket 3, M Key, Type 2260/2280/22110 PCIe 4.0 X4/X2 SSD Support) (M2P_CPU) (Note) Chipset: 1 X M.2 Connector (Socket 3, M Key, Type 2260/2280 SATA And PCIe 3.0 X4/ X2 SSD Support) (M2A_SB) 6 X SATA 6Gb/S Connectors Intel Optane Memory
    BrandGigabyte



    Find Gigabyte B560M DS3H Intel 10th and 11th Gen Micro ATX Motherboard Best Price in Bangladesh. Find also other Motherboard on reasonable from our website. You will get Gigabyte B560M DS3H home delivery in Dhaka city or pickup from our showroom.

    Gigabyte B560M DS3H Intel 10th and 11th Gen Micro ATX Motherboard Best Price in Bangladesh

    Basic Information

    Supported CPU11th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors
    10th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors / Intel Core i3 processors/ Intel Pentium processors / Intel Celeron processors
    ChipsetIntel B560 Express Chipset
    BIOS1 x 256 Mbit flash
    Use of licensed AMI UEFI BIOS
    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
    Form FactorMicro ATX Form Factor; 24.4cm x 24.4cm
    AudioRealtek Audio CODEC
    High Definition Audio
    2/4/5.1/7.1-channel

    Expansion Slots

    PCI1 x PCI Express x16 slot, running at x16
    (The PCIEX16 slot conforms to PCI Express 4.0 standard.) (Note)
    2 x PCI Express x1 slots
    (The PCIEX1 slot conforms to PCI Express 3.0 standard.)
    M.2 Socket1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_CPU) (Note)
    Chipset:
    1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/ x2 SSD support) (M2A_SB)

    Memory

    TypeDual-channel memory architecture
    Slots4 x DIMM
    Supported Memory11th Generation Intel Core i9/i7/i5 processors:
    Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133 MHz
    10th Generation Intel Core i9/i7 processors:
    Support for DDR4 2933/2666/2400/2133 MHz memory modules
    10th Generation Intel Core i5/i3/Pentium/Celeron processors:
    Support for DDR4 2666/2400/2133 MHz memory modules
    4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
    Dual channel memory architecture
    Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    Support for Extreme Memory Profile (XMP) memory modules
    Maximum Memory128 GB (32 GB single DIMM capacity)

    Graphics

    GraphicsIntegrated Graphics Processor-Intel HD Graphics support:
    1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
    1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
    * The DVI-D port does not support D-Sub connection by adapter.
    1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
    * Support for DisplayPort 1.2 version and HDCP 2.3
    * When the D-Sub port and DisplayPort are connected at the same time, images will output from the DisplayPort only.
    1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
    * Support for HDMI 1.4 version and HDCP 2.3.
    Support for up to 3 displays at the same time

    Connector & Ports

    HDMI1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
    Display Port (s)1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
    D-Sub (s)1 x D-Sub port
    DVI-D (s)1 x DVI-D port
    USB (s)Chipset:
    1 x USB Type-C port on the back panel, with USB 3.2 Gen 1 support
    5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)
    4 x USB 2.0/1.1 ports available through the internal USB headers
    Chipset+USB 2.0 Hub:
    2 x USB 2.0/1.1 ports on the back panel
    LAN Port (s)Realtek GbE LAN chip (1000/100 Mbit)
    Supported Storage1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_CPU) (Note)
    Chipset:
    1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/ x2 SSD support) (M2A_SB)
    6 x SATA 6Gb/s connectors
    Intel Optane Memory Ready
    Audio3 x audio jacks
    Internal I/O Ports
    1 x 24-pin ATX main power connector
    1 x 8-pin ATX 12V power connector
    1 x CPU fan header
    3 x system fan headers
    1 x addressable LED strip header
    1 x RGB LED strip header
    6 x SATA 6Gb/s connectors
    2 x M.2 Socket 3 connectors
    1 x front panel header
    1 x front panel audio header
    1 x USB 3.2 Gen 1 header
    2 x USB 2.0/1.1 headers
    1 x serial port header
    1 x parallel port header
    1 x Clear CMOS jumper
    1 x Q-Flash Plus button
    TPM (Trusted Platform Module )1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)

    Warranty Information

    Manufacturing Warranty03 years warranty

    Others

    Special FeaturesSupport for APP Center
    @BIOS
    EasyTune
    Fast Boot
    Game Boost
    ON/OFF Charge
    RGB Fusion
    Smart Backup
    System Information Viewer
    Support for Q-Flash Plus
    Support for Q-Flash
    Support for Xpress Install
    Bundled SoftwareNorton Internet Security (OEM version)
    Realtek 8118 Gaming LAN Bandwidth Control Utility

    Gigabyte B560M DS3H Intel 10th and 11th Gen Micro ATX Motherboard

    Gigabyte B560M DS3H Micro ATX Motherboard supports 11th and 10th Gen Intel Core Series Processors and Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs with Direct 6+2 Phases Digital VRM Solution with Low RDS(on) MOSFETs. It features Dual Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 and GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management. It has USB 3.2 Gen1 Type-C for Fast and Versatile Connections and High-Quality Audio Capacitors and Audio Noise Guard with LED Trace Path Lighting. It supports RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips and Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP. The Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card. It has 3 years warranty.
