Price:
9,200.00 ৳
Specifications
| HANDHELD TRANSMITTER | . |
| RF Output Power | 15mW (Max.) |
| Modulation Mode | FM (F3E) |
| Microphone Element | Dynamic, Cardioid |
| Dynamic Range | 80dB |
| Frequency Response | 50-12,000Hz |
| Current Consumption | ≤130mA |
| Power Requirement | 3V (2 × 1.5V AA Pencil Cells) |
| Controls | Transmitter ON/OFF Switch |
| Indication | Red LED for indicating transmitter ON |
| Dimensions | ø55 (L248) mm |
| Weight | 180g (w/o battery) |
| TIE-CLIP TRANSMITTER | . |
| RF Output Power | 15mW (Max.) |
| Modulation Mode | FM (F3E) |
| Microphone Element | Condenser, Omnidirectional |
| Dynamic Range | 80dB |
| Frequency Response | 80-15,000Hz |
| Current Consumption | ≤130mA |
| Power Requirement | 3V (2 × 1.5V AA Pencil Cells) |
| Controls | Transmitter ON/OFF Switch, Volume Control |
| Indication | Red LED for indicating transmitter ON |
| Dimensions | W67 x H32 x D95 mm |
| Weight | 60g (w/o battery) |
| RECEIVER | . |
| Frequency Stability | ± 0.005% Quartz Crystal Controlled |
| Receiving Method | Non-diversity |
| Audio Output | Channel 1: 0-55mV / 1kΩ, Channel 2: 0-55mV / 1kΩ Channel 1+2: 0-55mV / 1kΩ |
| Signal to Noise Ratio | > 80dB |
| Distortion | < 0.5% |
| Frequency Response | 50-15,000Hz |
| Antenna | Telescopic |
| Power Requirement | 240V AC 50Hz for AC adaptor (supplied along with) |
| Controls | Power On / Off Switch, Volume Control for Channel-1, Volume Control for Channel-2 |
| Indications | Red LED for Power ON, Green LED for RF reception on Channel-1, Green LED for RF reception on Channel-2 |
| Dimensions | W230 x H42 x D150 mm |
| Weight | 353g |
