Price:
8140,00 ৳
MSI H410M PRO-E Intel 10th Gen Micro-ATX Motherboard
Brand: MSI
Model: MSI H410M PRO-E
Supports 10th Gen Intel Core and Pentium Gold/ Celeron Processors
PCI-E Steel Armor
2x DDR4 Memory Slots
Intel LAN, Audio Boost, DDR4 Boost
| Supported CPU | Supports 10th Gen Intel Core And Pentium Gold/ Celeron Processors For LGA 1200 Socket |
|---|---|
| Chipset | Intel H410 Chipset |
| Supported Memory | Intel Core I7/ I9: Supports Up To DDR4 2933 MHz Intel Core I5 And Below: Supports Up To DDR4 2666 MHz Supports Dual-Channel Mode Supports Intel Extreme Memory Profile (XMP) |
| RAM Type | DDR4 |
| FromFactor | Mirco-ATX Form Factor 9.3 In. X 7.5 In. (23.6 Cm X 19.0 Cm) |
| Internal I/O Ports | 1x 24-Pin ATX Main Power Connector 1x 8-Pin ATX 12V Power Connector 4x SATA 6Gb/S Connectors 1x USB 2.0 Connector (Supports Additional 2 USB 2.0 Ports) 1x USB 3.2 Gen1 5Gbps Connector (Supports Additional 2 USB 3.2 Gen1 5Gbps Ports) 1x 4-Pin CPU Fan Connector 1x 4-Pin System Fan Connector 1x Front Panel Audio Connector 2x System Panel Connectors 1x Serial Port Connector 1x Chassis Intrusion Connector 1x Clear CMOS Jumper 4x EZ Debug LED |
| Maximum Memory | 64GB |
| Audio | Realtek ALC897 Codec 7.1-Channel High Definition Audio |
| HDMI | 1x HDMI 1.4 Port (Resolution Of 4096x2160 @30Hz) |
| LAN | 1x Realtek R1111H Gigabit LAN Controller |
| Graphics | 1x VGA Port, Supports A Maximum Resolution Of 2048x1536 @50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz |
| USB | Intel H410 Chipset 4x USB 3.2 Gen 1 5Gbps Ports (2 Type-A Ports On The Back Panel, 2 Ports Available Through The Internal USB 3.2 Gen 1 5Gbps Connector) 6x USB 2.0 Ports (4 Type-A Ports On The Back Panel, 2 Ports Available Through The Internal USB 2.0 Con |
| Wi-Fi | No |
| Supported Storage | Intel H410 Chipset 4x SATA 6Gb/S Ports |
| Brand | MSI |
MSI H410M PRO-E Intel 10th Micro-ATX Motherboard Best Price in Bangladesh
Find MSI H410M PRO-E Intel 10th Gen Micro-ATX Motherboard Best Price in Bangladesh. Find also other Motherboard on reasonable from our website.You will get home delivery in Dhaka city or pickup from our showroom.
Basic Information
| Supported CPU | Supports 10th Gen Intel Core and Pentium Gold/ Celeron processors for LGA 1200 socket |
| Chipset | Intel H410 Chipset |
| Form Factor | Mirco-ATX Form Factor 9.3 in. x 7.5 in. (23.6 cm x 19.0 cm) |
Expansion Slots
| PCI | 1x PCIe 3.0 x16 slot (From CPU) 1x PCIe 3.0 x1 slot (From PCH) |
Memory
| Type | Non-ECC, Un-Buffered Memory |
| Slots | 2x DDR4 memory slots |
| Supported Memory | Intel Core i7/ i9: Supports up to DDR4 2933 MHz Intel Core i5 and below: Supports up to DDR4 2666 MHz Supports Dual-Channel mode Supports Intel Extreme Memory Profile (XMP) |
| Maximum Memory | 64GB |
Graphics
| Graphics | 1x VGA port, supports a maximum resolution of 2048x1536 @50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz 1x HDMI™ 1.4 port, supports a maximum resolution of 4096x2160 @30Hz 1x DVI-D port, supports a maximum resolution of 1920x1200 @60Hz |
Connector & Ports
| HDMI | 1x HDMI 1.4 port (Resolution of 4096x2160 @30Hz) |
| DVI-D (s) | 1x DVI-D port (Resolution of 1920x1200 @60Hz) |
| USB (s) | Intel H410 Chipset 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB 3.2 Gen 1 5Gbps connector) 6x USB 2.0 ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 2.0 connector) |
| LAN Port (s) | 1x Realtek R1111H Gigabit LAN controller |
| Supported Storage | Intel H410 Chipset 4x SATA 6Gb/s ports |
| Audio | Realtek ALC897 Codec 7.1-Channel High Definition Audio |
| Internal I/O Ports | 1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 4x SATA 6Gb/s connectors 1x USB 2.0 connector (supports additional 2 USB 2.0 ports) 1x USB 3.2 Gen1 5Gbps connector (supports additional 2 USB 3.2 Gen1 5Gbps ports) 1x 4-pin CPU fan connector 1x 4-pin system fan connector 1x Front panel audio connector 2x System panel connectors 1x Serial port connector 1x Chassis Intrusion connector 1x Clear CMOS jumper 4x EZ Debug LED |
| TPM (Trusted Platform Module ) | 1 x TPM module connector |
Warranty Information
| Manufacturing Warranty | 03 Years Warranty |
MSI H410M PRO-E Intel 10th Micro-ATX Motherboard
MSI H410M PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, MSI H410M PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity. MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you to check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically. Stay connected with Intel LAN, optimized for stable internet throughput ideal for championship level online plays. MSI conducts thorough memory testing with the most popular memory brands under extreme conditions to ensure your system runs stable no matter what. Our memory partners include brands like Corsair, Crucial, Kingston, G.Skill and many more to optimize memory modules and configurations. Core Boost technology combines MSI's premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Creating a perfect condition to support multi-core CPU running at full speed.
| Brands | MSI |
